Tornado
525.21.1382.2
Thermex Tornado compact is an induction hob with built-in capacity all in one unit. With Thermex Typhoon compact, you don't need a hood above the hob. Documented em capture of over 75%
Thermex Tornado is the latest addition to Thermex when it comes to capacity built into the hob. The hob has heat regulation with 9-stages, boost on each cooking zone and of course a child safety lock. The kitchen hood part has a powerful, low-noise Eco motor that pulls steam down between the cooking zones. The built-in motor can produce up to 650 m3/h and it is so efficient that it meets the requirement of a minimum of 75% dust collection.
- 9-stage heat regulation + boost on each cooking zone
- Residual heat indicator
- 99 min. hours
- Child protection
- Great suction power of up to 650 m³/h
Specifications
Minimum airflow [m3/h]
225
Minimum-Soundpower [dB(A)]
52
Maximum-airflow [m3/h]
650
Maximum-Soundpower [dB(A)]
73
Control
Glass touch
Material
Black glass
Specifications
Minimum airflow [m3/h]
225
Minimum-Soundpower [dB(A)]
52
Maximum-airflow [m3/h]
650
Maximum-Soundpower [dB(A)]
73
Control
Glass touch
Material
Black glass
Weight and measurements
Maximum width [mm]
805
Maximum depth [mm]
520
Maximum height [mm]
205
Cooking zone rear-right [mm]
185 mm
Cooking zone rear-left [mm]
185 mm
Cooking zone front-right [mm]
165 mm
Cooking zone Front-left [mm]
165 mm
Installation dimensions WxD [mm]
765x495
Outlet dimension (mm)
220x90
Packaging width(mm)
870
Packaging depth [mm]
575
Packaging height(mm)
275
Net weight [kg]
18
Weight
22
Features
Control
Glass touch
Boost funktion
No
Indicator for filter cleaning
No
Moveable outlet
No
Built-in trigger function
No
Periodic room ventilation
No
Wi-Fi
No
Automatic bridge function
No
Boost function (Hob)
Yes
Bridge function
No
Child safety
Yes
Pot sensor
Yes
Keep warm function
No
Automatic boiling
No
Recall
No
Safety shutdown
No
Stop & Go
No
Timer on all cooking zones
Yes
Toplink compatible
No
Smarthome
No
Technical specifications
EEI-value
43.3
EEI-class
A+
Energy consumption in off mode (Po) [W]
0.45
GFE-value
46
GFE-class
F
FDE-value
30.9
FDE-class
A
Cooking area Rear-right [W]
2100
Cooking zone Rear-left [W]
2100
Cooking zone Front-right [W]
1500
Cooking zone Front-left [W]
1500
Total power of the hob [W]
7335
Power supply [V]
230
Moottorin maksimikulutus [W]
135
Other specifications
EAN
5703347532054
Type of grease filter
Aluminum filter
Number of filters
1
Carbon filter as accessory
Yes
Carbon filter code
535.21.8700.9
Number of carbonfilters
1
Number of speeds ex (boost)
3
Mounting
Table integrated
Motor type
Internal motor
Front panel color
Black
BodyColor
Black
Front panel material
Black glass
BodyColor (RAL)
9005
Material
Black glass
Number of cooking zones
4
Flush mounting
No
SupplyCord (m)
1
