Moon 100 – White
200.50.4001.2
Moon 100 in white is a round and quiet bathroom fan – with high reliability and classic design.
Color
Options
Elegant and quiet bathroom fan
The Thermex Moon 100 in white is a round fan with low noise levels and a classic design. It is suitable for bathrooms and smaller spaces where both function and aesthetics matter. High-quality ball bearings ensure stable and long-lasting operation.
The fan is operated manually – for example via a light switch – and is well suited for both new builds and renovations. The round white front panel creates a soft and harmonious look.
Features:
Manual control – no automation
Round and sleek white design
Ball bearings for long service life
Low noise level – only 32 dB(A)
Technical specifications:
Voltage: 230 V ~ 50 Hz
Power consumption: 15 W
Airflow: 100 m³/h
Sound pressure: 32 dB(A) at 3 metres
Speed: 2550 RPM
IP rating: IPX4
Insulation class: B
Operating temperature: 5 °C to 40 °C
Dimensions (DxH): Ø150 x 95 mm
Duct connection: Ø100 mm
Moon 100 – White is perfect if you’re looking for an elegant and quiet solution for daily ventilation.
- Manual control – on/off via switch
- Ball bearings for quiet operation and long lifespan
- Low noise level: 32 dB(A)
- White front in round shape
- Ø100 mm connection
Specifications
Energy consumption [W]
15
Luftmængde ved 0 Pascal [m3/t]
100
Kapslingsklasse
IPX4
Control
None
Material
Plastic
Voltage [V]
230
Specifications
Energy consumption [W]
15
Luftmængde ved 0 Pascal [m3/t]
100
Kapslingsklasse
IPX4
Control
None
Material
Plastic
Voltage [V]
230
Weight and measurements
Maximum width [mm]
152
Maximum depth [mm]
115
Maximum height [mm]
152
Aftræksdimension (mm)
Ø100
Packaging width(mm)
159
Packaging depth [mm]
120
Packaging height(mm)
156
Net weight [kg]
0.42
Weight
0.53
Features
Control
None
Timer funktion
Nej
Fugtsensor
Nej
Technical specifications
Energy consumption [W]
15
Kapslingsklasse
IPX4
Luftmængde ved 0 Pascal [m3/t]
100
Maximum sound pressure at 3 meters [dB(A)]
32
Voltage [V]
230
Other specifications
EAN
5703347206474
BodyColor
White
Material
Plastic
Max air temperature (° C)
40
Fan speed [rpm]
2550
