Winemex 5
910.21.1013.2
Winemex 5 from Thermex is a sleek wine storage drawer for built-in installation. Combining functionality and style, it’s the perfect solution for modern kitchens.
Winemex 5 is a stylish and modern wine storage drawer, crafted from black-painted steel with an elegant glass front. Designed for discreet installation, it replaces a standard 60 cm drawer, making it an ideal solution for those who want to integrate wine storage into their kitchen without compromising on aesthetics.
Features:
• Capacity: Holds up to 5 standard wine bottles, making it perfect for keeping your favorite wines stored perfectly.
• Single-zone storage: Temperature can be set between 5 to 20 degrees Celsius, allowing for optimal storage conditions for both white and red wines.
• Easy installation: The compact design ensures simple installation.
• Display: A digital display shows the temperature inside the drawer, allowing you to easily monitor and adjust conditions.
• Dimensions: The drawer is 595 mm wide and 141 mm high, making it easy to integrate into most standard kitchen layouts.
• Anti-UV glass: Protects wines from harmful UV rays, preserving their quality and flavor.
• Interior LED light: Highlights wine labels and adds a touch of exclusivity.
• Alarms: Door and temperature alarms ensure you are always aware of any deviations from the desired storage conditions.
Operation:
• Glass touch controls: When the drawer is opened, the glass touch panel becomes visible, offering an intuitive and easy way to control the unit's functions.
• Functions: Turn the wine cabinet and light on or off, set the temperature, and read the current temperature and other settings.
Cleaning:
The drawer can be wiped down with a damp cloth and a bit of cleaning solution to keep it in perfect condition. The glass front can be cleaned with window cleaner.
Winemex 5 from Thermex is an elegant wine storage drawer in black steel and glass front for built-in installation. It holds 5 bottles, features adjustable temperature and LED lighting, making it perfect for the modern kitchen.
- Capacity: Winemex 5 holds up to 5 standard wine bottles, allowing you to store your favorite wines in an ideal manner
- Temperature: With single-zone storage, the temperature can be set from 5 to 20 degrees Celsius, so both white and red wines can be stored under optimal conditions
- Installation: The compact design makes installation easy, and the drawer fits perfectly into a standard 60 cm kitchen drawer
- Features: The drawer is equipped with a digital display and glass touch controls, making it easy to turn the cabinet and light on or off and adjust the temperature
- Design: Made of black-painted steel with an elegant glass front and interior LED light, it protects wines from UV rays to preserve their quality and flavor
Specifications
Number of bottles
5
Climate class
ST (+18’C til +38’C)
Maximum Soundpower [dB(A)]
43
Energy consumption [W]
80
Number of zones
Enkeltzone skab
Temperature zone 1
5-20
Control
Glass touch
Material
Black painted steel
Specifications
Number of bottles
5
Climate class
ST (+18’C til +38’C)
Maximum Soundpower [dB(A)]
43
Energy consumption [W]
80
Number of zones
Enkeltzone skab
Temperature zone 1
5-20
Control
Glass touch
Material
Black painted steel
Weight and measurements
Maximum width [mm]
595
Maximum depth [mm]
553
Maximum height [mm]
134
Volume [L]
13
Packaging width(mm)
655
Packaging depth [mm]
685
Packaging height(mm)
210
Net weight [kg]
15
Weight
18
Features
Control
Glass touch
Defrosting
Automatic
Anti Vibration
No
Possibility to rehinge door
No
Winter function
No
Technical specifications
Energy consumption [W]
80
Energieffektivitetsindeks
158.8
Energieffektivitetsklasse(EEI)
G
Lampe forbrug (W)
0.15
Årligt energiforbrug
123
Climate class
ST (+18’C til +38’C)
Air circulation
No
Maximum Soundpower [dB(A)]
43
Type of plug
Schuko
Power supply [V]
230
Other specifications
EAN
5703347902291
BodyColor
Black
Material
Black painted steel
Number of bottles
5
Number of zones
Enkeltzone skab
Use of the appliance
The appliance is only intended for storing wine.
Installation type
Designed for built-in
SupplyCord (m)
1.8
Refrigerant
R600a
Refrigerant weight [g]
16
