Winemex Blue 5

910.21.2007.2
Winemex Blue 5 from Thermex is an elegant wine storage drawer in black-painted steel that integrates discreetly into your kitchen. With space for 5 bottles, single-zone temperature control (5-20°C), LED lighting, and glass touch controls, it combines style and functionality.

Winemex Blue 5 is an elegant and modern wine storage solution designed to integrate seamlessly with your kitchen. The drawer is made of black-painted steel, providing a sleek and timeless look. It is delivered without a front panel, allowing you to easily attach a drawer front that matches the rest of your kitchen. This ensures a discreet and harmonious built-in appearance, replacing a standard 60 cm drawer.

Features:
• Capacity: Holds up to 5 standard wine bottles, making it ideal for keeping your favorite wines stored perfectly.
• Single-zone storage: Temperature can be set between 5 and 20 degrees Celsius, allowing both white and red wines to be stored under optimal conditions.
• Easy installation: The compact design ensures simple installation.
• Display: A digital display shows the temperature inside the drawer, so you can easily monitor and adjust the conditions.
• Dimensions: The drawer is 595 mm wide and 141 mm high, making it easy to integrate into most standard kitchen designs.
• Interior LED light: Highlights wine labels and adds an exclusive touch.
• Alarms: Door and temperature alarms ensure that you are always aware of any deviations from the desired storage conditions.

Operation:
• Glass touch controls: When the drawer is opened, the glass touch panel becomes visible, offering an intuitive and easy way to control the unit's functions.
• Functions: Turn the wine cabinet and light on or off, adjust the temperature, and read the current temperature and other settings.

Cleaning:
The drawer can be wiped down with a damp cloth and a bit of cleaning solution to keep it in perfect condition.


Winemex Blue 5 from Thermex combines functionality and style in a compact and exclusive wine storage solution that fits perfectly into the modern kitchen.

  • Capacity: Winemex Blue 5 holds up to 5 standard wine bottles, making it easy to store your favorite wines in an ideal manner
  • Temperature: With single-zone storage, the temperature can be set from 5 to 20 degrees Celsius, allowing both white and red wines to be stored under optimal conditions
  • Installation: The compact design makes installation simple, and the drawer fits perfectly into a standard 60 cm kitchen drawer
  • Features: The drawer is equipped with a digital display and glass touch controls, allowing you to easily turn the cabinet and light on or off, as well as adjust the temperature
  • Design: Delivered without a front for easy attachment of a kitchen-matching drawer front for a discreet built-in look. This ensures that the wine drawer integrates seamlessly with all kitchen designs

Specifications

Number of bottles
5
Climate class
ST (+18’C til +38’C)
Maximum Soundpower [dB(A)]
43
Energy consumption [W]
80
Number of zones
Enkeltzone skab
Temperature zone 1
5-20
Control
Glass touch
Material
Black painted steel
Voltage [V]
230

Specifications

Number of bottles
5
Climate class
ST (+18’C til +38’C)
Maximum Soundpower [dB(A)]
43
Energy consumption [W]
80
Number of zones
Enkeltzone skab
Temperature zone 1
5-20
Control
Glass touch
Material
Black painted steel
Voltage [V]
230

Weight and measurements

Maximum width [mm]
595
Maximum depth [mm]
557
Maximum height [mm]
134
Volume [L]
13
Packaging width(mm)
655
Packaging depth [mm]
685
Packaging height(mm)
210
Net weight [kg]
14.5
Weight
17.5

Features

Control
Glass touch
Defrosting
Automatic
Anti Vibration
No
Possibility to rehinge door
No
Winter function
No

Technical specifications

Energy consumption [W]
80
Energieffektivitetsindeks
158.8
Energieffektivitetsklasse(EEI)
G
Lampe forbrug (W)
0.15
Årligt energiforbrug
123
Climate class
ST (+18’C til +38’C)
Air circulation
No
Maximum Soundpower [dB(A)]
43
Type of plug
Schuko
Voltage [V]
230

Other specifications

EAN
5703347902307
BodyColor
Black
Material
Black painted steel
Number of bottles
5
Number of zones
Enkeltzone skab
Use of the appliance
The appliance is only intended for storing wine.
Installation type
Designed for built-in
SupplyCord (m)
1.8
Refrigerant
R600a
Refrigerant weight [g]
16

Downloads

Here you will find all documents relevant to this product

Product info

Dimensional drawing

Installation manual

Teknisk info
