Passat II - 120x60 cm - white w / motor

423.46.6261.2
Thermex Passat II in white with motor is a minimalist built-in hood that can be hidden in the kitchen or in the ceiling. The motor is an energy-efficient Eco motor, which ensures a low noise level
Motor type
Please select variant!

Thermex Passat II is an exclusive ceiling-integrated hood. Thermex «All Options» solution makes it adaptable to all homes and all types of exhaust and ventilation systems, including Thermex Plasmex® .

The hood can be controlled using the included remote control or automatically via the hob with Thermex Thermex Toplink® . In addition, you can operate the hood via the Thermex Remote app, which can be downloaded for free in App store and Google Play. In the app, it is possible to adjust the brightness of the light, activate periodic extraction and get a status-indication of the filter.

The hood comes with Voicelink functionality built into the hood. These functions allow you to control the hood with your voice via Google Assistant ("Hey Google!") . So there are plenty of options to choose from to operate your Thermex Passat II. The ceiling-mounted cooker hood will give an aesthetic look of your kitchen, while keeping your kitchen and associated room completely free for cooking steam using the powerfull motor, which can move up to 750 m3/h.

Specifications

Minimum airflow [m3/h]
190
Minimum-Soundpower [dB(A)]
44
Maximum-airflow [m3/h]
400
Maximum-Soundpower [dB(A)]
59
Airflow with boost [m3/h]
750
Soundpower boost [dB(A)]
73
Control
Remote control
Material
White painted steel and White glass

VoiceLink

Control your Thermex hood by using your voice alone - this applies to both the hood's suction power and light. This gives you the freedom to use your hands for other things when you are in the kitchen.

Read more

Wifi

The Wifi function means that the product communicates wirelessly via Wifi. All private homes today have Wifi, which offers many options in connection with electronic ventilation products.

App control

With the App control, you can access your Thermex product via your smartphone. It turns your smartphone into a remote control, so you always have full control. In the app, there are more functions than you find on the normal operation.

Metal filter

The metal filter is the traditional filter that everyone knows. This ensures that the grease from the hood does not end up inside the hood or in the duct system. The metal filter can be washed in the dishwasher.

Remote control

The remote control makes it easy and convenient to operate your Thermex product. You don't even have to get up - Then it doesn't get any easier.

Light dimmer

Using the dimmer function, you can adjust the brightness of the work light in the scope. The lighting in kitchens is very different, so with dimmers you can adjust the amount of light to suit your needs.

Edge suction

Hoods with edge suction has an exclusive design with the filters hidden inside the hood. Edge suction creates air currents all the way around the cooking zone. It is these air currents that effectively trap the food.

Periodic extraction

Periodic extraction is a function of the hood which makes it possible to use the hood as an aid for ventilation in the home. You can e.g. set the hood to start for 10 minutes per hour.

Timer function

With the timer function, the product continues to extract for a short period after you would normally switch it off. In this way, you are sure that you have ventilated thoroughly. It helps to ensure a good indoor climate.

Filter cleaning indicator

The filter cleaning indicator is a timer that reminds you to remember to clean the filter in the hood. It is not a sensor, but a timer that gives a notification after a period of time.

Specifications

Minimum airflow [m3/h]
190
Minimum-Soundpower [dB(A)]
44
Maximum-airflow [m3/h]
400
Maximum-Soundpower [dB(A)]
59
Airflow with boost [m3/h]
750
Soundpower boost [dB(A)]
73
Control
Remote control
Material
White painted steel and White glass

Weight and measurements

Maximum width [mm]
1200
Maximum depth [mm]
600
Maximum height [mm]
199
Outlet dimension (mm)
220x90
Packaging width(mm)
1320
Packaging depth [mm]
710
Packaging height(mm)
320
Net weight [kg]
34
Weight
39

Features

Control
Remote control
Boost funktion
Yes
Decor light
No
Eftersug
Ja
Indicator for filter cleaning
Yes
Moveable outlet
Yes
Built-in trigger function
Yes
Light dimmer
Yes
Periodic room ventilation
Yes
Wi-Fi
Yes
Toplink compatible
Yes
Smarthome
Yes

Technical specifications

Illumination (Emiddle) [lux]
369
LE value [lux/W]
51.3
LE-class
G
EEI-value
31.7
EEI-class
A++
Energy consumption in off mode (Po) [W]
0.49
Lamp consumption [W]
2.4
Total consumption of light (WL) [W]
7.2
GFE-value
76.4
GFE-class
C
FDE-value
40.6
FDE-class
A
Type of plug
Schuko
Power supply [V]
230
Energiforbrug standby (Ps) [W]
0.49
Moottorin maksimikulutus [W]
220

Other specifications

EAN
5703347532009
Type of grease filter
Aluminum filter
Number of filters
2
Carbon filter as accessory
Yes
Carbon filter code
535.46.2000.9
Number of carbonfilters
2
Number of speeds ex (boost)
3
Number of lamps
3
Suction Bottom
No
Suction Front
No
Suction Edge
Yes
Mounting
Ceiling Integrated
Motor type
Internal motor
Front panel color
White
BodyColor
White
Front panel material
White glass
BodyColor (RAL)
9016
Material
White painted steel and White glass
SupplyCord (m)
1.5

Downloads

Here you will find all documents relevant to this product

Product info

Dimensional drawing

Installation manual

User manual

Teknisk info

Exhaust fittings
