Passat II - 120x60 cm - white without motor
423.46.6261.0
Motor type
Specifications
Control
Remote control
Material
White painted steel and White glass
Weight and measurements
Maximum width [mm]
1200
Maximum depth [mm]
600
Maximum height [mm]
117
Outlet dimension (mm)
Ø150
Packaging width(mm)
1320
Packaging depth [mm]
710
Packaging height(mm)
320
Net weight [kg]
27.5
Weight
32.5
Features
Control
Remote control
Boost funktion
Yes
Decor light
No
Eftersug
Ja
Indicator for filter cleaning
Yes
Moveable outlet
No
Built-in trigger function
Yes
Light dimmer
Yes
Periodic room ventilation
Yes
Wi-Fi
Yes
Toplink compatible
Yes
Smarthome
Yes
Technical specifications
Illumination (Emiddle) [lux]
369
LE value [lux/W]
51.3
LE-class
G
Lamp consumption [W]
2.4
Total consumption of light (WL) [W]
7.2
GFE-value
76.4
GFE-class
C
Type of plug
Schuko
Power supply [V]
230
Other specifications
EAN
5703347531996
Type of grease filter
Aluminum filter
Number of filters
2
Number of speeds ex (boost)
3
Number of lamps
3
Suction Bottom
No
Suction Front
No
Suction Edge
Yes
Mounting
Ceiling Integrated
Motor type
External motor
Front panel color
White
BodyColor
White
Front panel material
White glass
BodyColor (RAL)
9016
Material
White painted steel and White glass
SupplyCord (m)
1.5
Downloads
Here you will find all documents relevant to this product
