Passat Medio II - 90x50 cm - white w/motor
423.46.6251.2
Motor type
Specifications
Minimum airflow [m3/h]
190
Minimum-Soundpower [dB(A)]
44
Maximum-airflow [m3/h]
400
Maximum-Soundpower [dB(A)]
59
Airflow with boost [m3/h]
750
Soundpower boost [dB(A)]
73
Control
Remote control
Material
White painted steel and White glass
Voltage [V]
230
Weight and measurements
Maximum width [mm]
890
Maximum depth [mm]
490
Maximum height [mm]
199
Outlet dimension (mm)
220x90
Packaging width(mm)
1000
Packaging depth [mm]
620
Packaging height(mm)
330
Net weight [kg]
24.5
Weight
28
Features
Control
Remote control
Boost funktion
Yes
Decor light
No
Eftersug
Ja
Indicator for filter cleaning
Yes
Moveable outlet
Yes
Built-in trigger function
Yes
Light dimmer
Yes
Periodic room ventilation
Yes
Wi-Fi
Yes
Toplink compatible
Yes
Smarthome
Yes
Technical specifications
Illumination (Emiddle) [lux]
369
LE value [lux/W]
51.3
LE-class
A
EEI-value
31.7
EEI-class
A++
Energy consumption in off mode (Po) [W]
0.49
Colour temperature [Kelvin]
3000
GFE-value
76.4
GFE-class
C
FDE-value
40.6
FDE-class
A
Type of plug
Schuko
Energiforbrug standby (Ps) [W]
0.49
Voltage [V]
230
Other specifications
EAN
5703347532238
Type of grease filter
Aluminum filter
Number of filters
2
Carbon filter as accessory
Yes
Carbon filter code
535.46.2000.9
Number of carbonfilters
2
Number of speeds ex (boost)
3
Number of lamps
3
Suction Bottom
No
Suction Front
No
Suction Edge
Yes
Mounting
Ceiling Integrated
Motor type
Internal motor
Front panel color
White
BodyColor
White
Front panel material
White glass
Material
White painted steel and White glass
SupplyCord (m)
1.5
