Typhoon

525.21.1282.2
Thermex Tyhpoon compact is an induction hob with built-in capacity all in one unit. With Thermex Typhoon compact, you don't need a hood above the hob. Thermex Typhoon documented em capture over 75%

The Thermex Typhoon is the latest addition to Thermex when it comes to hoods built into the hob. The hob has heat regulation with 9-stages, boost on each cooking zone and of course a child safety lock. The scope part has a powerful, low-noise Eco motor that pulls steam down between the cooking zones. The built-in motor can produce up to 623 m3/h and it is so efficient that it meets the requirement of a minimum of 75% dust collection.

Specifications

Minimum airflow [m3/h]
225
Minimum-Soundpower [dB(A)]
55
Maximum-airflow [m3/h]
623
Maximum-Soundpower [dB(A)]
73
Control
Glass touch
Material
Black glass
Voltage [V]
230

Metal filter

The metal filter is the traditional filter that everyone knows. This ensures that the grease from the hood does not end up inside the hood or in the duct system. The metal filter can be washed in the dishwasher.

Glass touch

The Glastouch control is an elegant solution to the normal control, which goes together with the hood. As the operation is behind a glass panel, cleaning the hood is even easier with the glass touch.

Timer function

With the timer function, the product continues to extract for a short period after you would normally switch it off. In this way, you are sure that you have ventilated thoroughly. It helps to ensure a good indoor climate.

Specifications

Minimum airflow [m3/h]
225
Minimum-Soundpower [dB(A)]
55
Maximum-airflow [m3/h]
623
Maximum-Soundpower [dB(A)]
73
Control
Glass touch
Material
Black glass
Voltage [V]
230

Weight and measurements

Maximum width [mm]
805
Maximum depth [mm]
520
Maximum height [mm]
205
Cooking zone rear-right [mm]
185
Cooking zone rear-left [mm]
Ø185
Cooking zone front-right [mm]
165
Cooking zone Front-left [mm]
165
Installation dimensions WxD [mm]
765x495
Outlet dimension (mm)
220x90
Packaging width(mm)
870
Packaging depth [mm]
575
Packaging height(mm)
275
Net weight [kg]
18
Weight
22

Features

Control
Glass touch
Boost funktion
No
Indicator for filter cleaning
No
Moveable outlet
No
Built-in trigger function
No
Periodic room ventilation
No
Wi-Fi
No
Bridge function
No
Automatic bridge function
No
Boost function
Yes
Child safety
Yes
Pot sensor
Yes
Keep warm function
No
Automatic boiling
No
Recall
No
Safety shutdown
No
Stop & Go
No
Toplink compatible
No
Smarthome
No
Timer function
Yes

Technical specifications

EEI-value
43.3
EEI-class
A+
Energy consumption in off mode (Po) [W]
0.45
GFE-value
46
GFE-class
F
FDE-value
30.9
FDE-class
A
Cooking area Rear-right [W]
2100
Cooking zone Rear-left [W]
2100
Cooking zone Front-right [W]
1500
Cooking zone Front-left [W]
1500
Total power of the hob [W]
7335
Power supply [V]
230
Motor Power [W]
135
Voltage [V]
230

Other specifications

EAN
5703347531026
Type of grease filter
Aluminum filter
Number of filters
1
Carbon filter as accessory
Yes
Carbon filter code
535.21.8700.9
Number of carbonfilters
1
Number of speeds ex (boost)
3
Mounting
Table integrated
Motor type
Internal motor
Front panel color
Black
BodyColor
Black
Front panel material
Black glass
Material
Black glass
Number of cooking zones
4
Flush mounting
No
SupplyCord (m)
1
