Design Line 8002 - vertical cooker hood - 80 cm

540.23.2282.2
Elegant vertical cooker hood in black glass with powerful and quiet DC motor, adjustable lighting and energy class A+++ for modern kitchens.
Width
Please select variant!

Thermex Design Line 8002 – 80 cm is an elegant and modern vertical cooker hood in black glass and metal that combines exclusive design with efficient performance for larger hobs.

Design and functionality
Design Line 8002 in 80 cm has a stylish vertical design and a reduced height, which gives a modern and airy look in the kitchen. The wide model is ideal for larger stoves and open kitchen solutions, and the slim shape means that you avoid bumping your head while cooking. The black glass front and elegant lines underline an exclusive and timeless look.

Features and Operation
The cooker hood is equipped with a powerful, brushless DC motor with a suction power of up to 740 m³/h. The motor is both energy-efficient and quiet, and the high performance ensures fresh air and effective removal of cooking vapours. With energy efficiency class A+++, the Design Line 8002 combines maximum efficiency with minimal energy consumption, making it both environmentally friendly and economical to operate.

Noise level
The advanced brushless motor ensures a low noise level from just 42 dB(A), so you can enjoy the peace of the kitchen even when the hood is running at high power. This makes it ideal for open kitchen-dining rooms, where comfort and sound level play an important role.

Lighting and Controls
The adjustable LED lighting allows you to adjust both brightness and colour temperature – from warm to cool white – so you can create the right ambience for cooking or dining. The cooker hood can be operated via remote control, Thermex Toplink® (optional) or the Thermex Remote app. It also supports voice control via Google Assistant, so you can easily control the functions with your voice.

Easy cleaning
The durable metal filters are easy to remove by opening the lower glass plate. The filters are dishwasher safe, making cleaning quick and convenient – a convenient solution for everyday use.

Installation
The Design Line 8002 in 80 cm can be installed both with and without a flue, which provides great flexibility in installation and makes it suitable for many different kitchen types and layouts.

The Thermex Design Line 8002 – 80 cm unites exclusive design, high performance and energy-efficient technology in an elegant and spacious solution for modern kitchens.

  • Exclusive design in black glass and metal
  • Powerful brushless DC motor with up to 740 m³/h suction power
  • Low noise level from just 42 dB(A)
  • Adjustable LED lighting in brightness and colour temperature
  • Easy operation via remote control, app and voice control

Specifications

Minimum airflow [m3/h]
240
Minimum-Soundpower [dB(A)]
42
Maximum-airflow [m3/h]
550
Maximum-Soundpower [dB(A)]
61
Airflow with boost [m3/h]
740
Soundpower boost [dB(A)]
67
Energy consumption [W]
163
Control
Remote control
Material
Black painted steel and Black glass
Voltage [V]
230

Specifications

Minimum airflow [m3/h]
240
Minimum-Soundpower [dB(A)]
42
Maximum-airflow [m3/h]
550
Maximum-Soundpower [dB(A)]
61
Airflow with boost [m3/h]
740
Soundpower boost [dB(A)]
67
Energy consumption [W]
163
Control
Remote control
Material
Black painted steel and Black glass
Voltage [V]
230

Weight and measurements

Maximum width [mm]
800
Maximum depth [mm]
340
Maximum height [mm]
1330
Vent pipe width (mm)
255
Vent pipe max height (mm)
930
Vent pipe min height (mm)
480
Longer vent pipe length (mm)
1950
Outlet dimension (mm)
Ø150
Packaging width(mm)
750
Packaging depth [mm]
900
Packaging height(mm)
460
Net weight [kg]
22
Weight
24

Features

Control
Remote control
Moveable outlet
Yes
Built-in trigger function
Yes
Wi-Fi
Yes

Technical specifications

Illumination (Emiddle) [lux]
312
LE value [lux/W]
78
LE-class
A
EEI-value
29.9
EEI-class
A+++
Colour temperature [Kelvin]
3000
Lamp consumption [W]
2
Total consumption of light (WL) [W]
4
GFE-value
62
GFE-class
E
FDE-value
41.2
FDE-class
A
AEC [kWh/h]
26.2
Energy consumption [W]
163
Type of plug
Schuko
Energiforbrug standby (Ps) [W]
0.45
Motor Power [W]
160
Voltage [V]
230

Other specifications

EAN
5703347534874
Number of filters
2
Carbon filter as accessory
Yes
Carbon filter code
535.23.0545.9
Number of carbonfilters
2
Number of speeds ex (boost)
3
Vent pipe modification
Yes
Motor type
Internal motor
Front panel color
Black
BodyColor
Black
Front panel material
Black glass
Material
Black painted steel and Black glass
SupplyCord (m)
1.7
Battery type
CR2032
Number of batteries
1

Downloads

Here you will find all documents relevant to this product

Product info

Dimensional drawing

Installation manual

Teknisk info
