Specifications
Minimum airflow [m3/h]
249.2
Minimum-Soundpower [dB(A)]
47
Maximum-airflow [m3/h]
511.9
Maximum-Soundpower [dB(A)]
60
Soundpower boost [dB(A)]
0
Control
Glass touch
Material
Black painted steel and Black glass
Weight and measurements
Maximum width [mm]
600
Maximum depth [mm]
387
Maximum height [mm]
1443
Vent pipe width (mm)
305
Vent pipe max height (mm)
980
Vent pipe min height (mm)
530
Outlet dimension (mm)
Ø150
Packaging width(mm)
540
Packaging depth [mm]
655
Packaging height(mm)
470
Net weight [kg]
19
Weight
21.5
Features
Control
Glass touch
Moveable outlet
No
Built-in trigger function
No
Wi-Fi
No
Technical specifications
Illumination (Emiddle) [lux]
84
LE value [lux/W]
28
LE-class
A
EEI-class
A++
Energy consumption in off mode (Po) [W]
0.43
Colour temperature [Kelvin]
3000
Lamp consumption [W]
1.5
Total consumption of light (WL) [W]
3
GFE-value
66.1
GFE-class
D
FDE-value
34.9
FDE-class
A
Power supply [V]
230
Odour extraction test standard
Other specifications
EAN
5703347967955
Number of filters
2
Carbon filter as accessory
Yes
Carbon filter code
535.21.8400.9
Number of carbonfilters
2
Number of speeds ex (boost)
3
Vent pipe modification
Yes
Motor type
Internal motor
Front panel color
Black
BodyColor
Black
Front panel material
Black glass
Material
Black painted steel and Black glass
SupplyCord (m)
1.3
Downloads
Here you will find all documents relevant to this product
