Glossy 60
540.21.1262.2
Width
Specifications
Minimum airflow [m3/h]
249.2
Minimum-Soundpower [dB(A)]
47
Maximum-airflow [m3/h]
511.9
Maximum-Soundpower [dB(A)]
60
Soundpower boost [dB(A)]
0
Control
Glass touch
Material
Black painted steel and Black glass
Voltage [V]
230
Weight and measurements
Maximum width [mm]
600
Maximum depth [mm]
387
Maximum height [mm]
1443
Vent pipe width (mm)
305
Vent pipe max height (mm)
980
Vent pipe min height (mm)
530
Outlet dimension (mm)
Ø150
Packaging width(mm)
540
Packaging depth [mm]
655
Packaging height(mm)
470
Net weight [kg]
19
Weight
21.5
Features
Control
Glass touch
Moveable outlet
No
Built-in trigger function
No
Wi-Fi
No
Technical specifications
Illumination (Emiddle) [lux]
84
LE value [lux/W]
28
LE-class
A
EEI-class
A++
Energy consumption in off mode (Po) [W]
0.43
Colour temperature [Kelvin]
3000
Lamp consumption [W]
1.5
Total consumption of light (WL) [W]
3
GFE-value
66.1
GFE-class
D
FDE-value
34.9
FDE-class
A
Odour extraction test standard
Voltage [V]
230
Other specifications
EAN
5703347967955
Number of filters
2
Carbon filter as accessory
Yes
Carbon filter code
535.21.8400.9
Number of carbonfilters
2
Number of speeds ex (boost)
3
Vent pipe modification
Yes
Motor type
Internal motor
Front panel color
Black
BodyColor
Black
Front panel material
Black glass
Material
Black painted steel and Black glass
SupplyCord (m)
1.3
