Specifications
Minimum airflow [m3/h]
223
Minimum-Soundpower [dB(A)]
59
Maximum-airflow [m3/h]
351.8
Maximum-Soundpower [dB(A)]
67
Energy consumption [W]
49.6
Control
Slide buttons
Material
White painted steel
Voltage [V]
230
Weight and measurements
Maximum width [mm]
600
Maximum depth [mm]
420
Maximum height [mm]
195
Outlet dimension (mm)
Ø150
Packaging width(mm)
235
Packaging depth [mm]
650
Packaging height(mm)
360
Net weight [kg]
5.5
Weight
6.5
Features
Control
Slide buttons
Boost funktion
No
Decor light
No
Eftersug
Nej
Indicator for filter cleaning
No
Moveable outlet
No
Built-in trigger function
No
Light dimmer
No
Periodic room ventilation
No
Wi-Fi
No
Toplink compatible
No
Smarthome
No
Technical specifications
Illumination (Emiddle) [lux]
114
LE value [lux/W]
57
LE-class
A
EEI-value
65.4
EEI-class
B
Colour temperature [Kelvin]
3000
Lamp consumption [W]
2
Total consumption of light (WL) [W]
2
GFE-value
65.2
GFE-class
D
FDE-value
13.1
FDE-class
D
Energy consumption [W]
49.6
Power supply [V]
230
Odour extraction test standard
Voltage [V]
230
Other specifications
EAN
5703347533075
Type of grease filter
Aluminum filter
Number of filters
2
Carbon filter as accessory
Yes
Carbon filter code
535.21.8310.9
Number of carbonfilters
2
Number of speeds ex (boost)
2
Number of lamps
1
Suction Bottom
No
Suction Front
No
Suction Edge
No
Mounting
Extract
Motor type
Internal motor
Front panel color
White
BodyColor
White
Front panel material
White lacquered steel
Material
White painted steel
SupplyCord (m)
1.2
