Specifications
Minimum airflow [m3/h]
219.4
Minimum-Soundpower [dB(A)]
61
Maximum-airflow [m3/h]
299.5
Maximum-Soundpower [dB(A)]
68
Energy consumption [W]
48.5
Control
Push buttons
Material
Black glass
Weight and measurements
Maximum width [mm]
600
Maximum depth [mm]
263
Maximum height [mm]
1075
Vent pipe width (mm)
222
Vent pipe max height (mm)
780
Vent pipe min height (mm)
400
Minimum length vent pipe cutdown [mm]
400
Outlet dimension (mm)
Ø150
Packaging width(mm)
320
Packaging depth [mm]
660
Packaging height(mm)
370
Net weight [kg]
8.8
Weight
10.2
Features
Control
Push buttons
Boost funktion
No
Decor light
No
Eftersug
Nej
Indicator for filter cleaning
No
Moveable outlet
No
Built-in trigger function
No
Light dimmer
No
Periodic room ventilation
No
Wi-Fi
No
Toplink compatible
No
Smarthome
No
Technical specifications
Illumination (Emiddle) [lux]
268
LE value [lux/W]
67
LE-class
A
EEI-value
66.3
EEI-class
B
Colour temperature [Kelvin]
3000
Lamp consumption [W]
4
Total consumption of light (WL) [W]
4
GFE-value
86.3
GFE-class
D
FDE-value
13.2
FDE-class
D
Energy consumption [W]
48.5
Power supply [V]
230
Energiforbrug standby (Ps) [W]
0.48
Odour extraction test standard
Other specifications
EAN
5703347533099
Type of grease filter
Aluminum filter
Number of filters
1
Carbon filter as accessory
Yes
Carbon filter code
535.21.8320.9
Number of carbonfilters
2
Number of speeds ex (boost)
3
Number of lamps
2
Suction Bottom
No
Suction Front
No
Suction Edge
No
Longer vent pipe available
No
Vent pipe modification
Yes
Mounting
Wall mounted
Motor type
Internal motor
Front panel color
Black
BodyColor
Black
Front panel material
Black glass
Material
Black glass
SupplyCord (m)
1.2
